Aiphone IS SERIES Installation Manual

6
CONNECTIONS
System connection diagram
The following is an example of standard (IP) system connection diagram.
Refer to page 9 to 26 for details about each unit connection.*
IP
IS-IPC
*1
IS-CCU
IS-RCU
IS-SCU
IS-RS
IS-RS
IS-RS
IS-MV
IS-DV/IS-DVF
/IS-SS
IS-DV/IS-DVF
/IS-SS
IS-MV
PT
PT
IS-SS
IS-PU-UL
IS-PU-S
IS-PU-UL
IS-PU-S
IS-PU-UL
IS-PU-S
IS-PU-UL
IS-PU-S
Local system
(Max.8)
(Max. 8)
(Max. 4)
(Max. 4)
(Max. 2)
(Max. 4)
(Max. 1)
(Max. 30)
To Internet/WAN
Monitor
Monitor
Recorder
Recorder
Broadband
router
Call button
Strobe light
Switch (Hub)
PBX / Telephone
EL-12S
Electric door strike
EL-12S
Electric door
strike
AC
transformer
AC
transformer
PA speaker
PA amplifi er
CD player
Timer
PA amplifi er
PA amplifi er
PA speaker
PA speaker
8Ω speaker
*1: An IP control unit (IS-IPC) is needed to connect a local system to a standard (IP) system.
