Aiphone IX-DVF Web Setting Manual

13
Introduction
4.1.5 Replace a station
Use this flowchart to replace a station.
Can the Web server of the station to be replaced be accessed?
YES NO
1. Back up the setting file of the station to be
replaced.
“Settings File Backup (→page 153)”
1. Replace the station.
2. Replace the station. 2. Restore the stored setting file to the newly
installed station.
If the station setting file is modified after being stored, those
changes will not be reflected.
“Settings File Backup (→page 153)”
3. Restore the backup setting file to the newly
installed station.
“Settings File Backup (→page 153)”
4. Done. 3. Done.

Aiphone IX-DVF Specifications

General

Resolution	720p
Video Compression	H.264
Ingress Protection	IP65
Vandal Resistance	IK08
Operating Voltage	48 VDC (PoE)
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-40° to 140°F (-40° to 60°C)
Communication	IP
Call Tone	Chime
