Aiphone IX-DVF Web Setting Manual

74
Configuring the Station
2.5 Video (IX-DV and IX-DVF(-*) only)
2.5.1 Video Encoder 1
Configure settings for videos during calls between IX system stations, during communication, and during calls with
VoIP phones. The coding system will be H.264 / AVC.
■ Resolution
■ Frame Rate [fps]
Description Choose the resolution.
Settings • 320×240 (QVGA)
• 640×480 (VGA)
Default values 640×480 (VGA)
Description Choose the frame rate.
Settings 1, 2, 3, 5, 7.5, 10, 15, 20, 30 fps
When set to 7.5, 10, 15, 20, or 30 fps, the frame rate will drop to 5 fps once approximately 10
minutes have elapsed after an outgoing call is made.
Default values 15 fps
Note
• The frame rate may be lower than the set value depending on the video being sent, the number of recipient stations, and the
network environment.

Aiphone IX-DVF Specifications

General

Resolution	720p
Video Compression	H.264
Ingress Protection	IP65
Vandal Resistance	IK08
Operating Voltage	48 VDC (PoE)
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-40° to 140°F (-40° to 60°C)
Communication	IP
Call Tone	Chime
