Introduction
4.3 For static IPv6 address
4.3.1 Create new data
Use this flowchart to create a new setting file, e.g., when installing a new system.
Important
• Save the settings after configuring the system. Refer to “Settings File Backup (→page 153)”.
• If the setting data is not saved, it may be impossible to restore it after maintenance or after-sales servicing.
1. Connect a PC to the station to be configured.
The default IP addresses of the stations are identical. Connect one at a time.
“Connecting to a PC (→page 44)”
2. With the default IPv4 Address, log in to the Web server of the station to be configured.
“Log in to the Web server of the station to be configured (→page 45)”
3. Set "Static / DHCP" to "Static IPv6" and configure "IPv6 Address."
“Static / DHCP (→page 66)”
The station will be restarted with the assigned IPv6 Address.
4. Configure IPv6 addresses for other stations.
5. Log in to the Web server of each station with the assigned IPv6 address.
“Log in to the Web server of the station to be configured (→page 45)”
6. Configure “Language (→page 63)”.
Click [Update] to update the settings.
7. Configure the station.
"Configuring the station" “Configuring the Station (→page 59)”
Refer to "Web Setting Manual" for each station.
8. Done.

Aiphone IX-DVF Specifications

General

Resolution	720p
Video Compression	H.264
Ingress Protection	IP65
Vandal Resistance	IK08
Operating Voltage	48 VDC (PoE)
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-40° to 140°F (-40° to 60°C)
Communication	IP
Call Tone	Chime
