Aiphone IX-DVF Web Setting Manual

75
Configuring the Station
■ Select Profile
■ I-picture interval♦
■ Bit rate [kbps]
■ RTP Start Port♦
■ RTP End Port♦
Description Configure the profile.
Settings • Baseline
• Main
• High
Default values Main
Description Configure the interval at which I-pictures are sent.
Settings 1 - 100
Default values 15
Description Set the bit rate.
Settings 32, 64, 128, 256, 384, 512, 768, 1024, 2048 kbps
Default values 1024 kbps
Note
• The bit rate may be lower than the set value depending on the video being sent, the number of recipient stations, and the
network environment.
Description Configure the range of ports communicating RTP.
The difference of (RTP Start Port) - (RTP End Port) should be 90 or greater.
If this is less than 90, a port outside the range may be used.
Settings 1 - 65534
Default values 30000
Description Configure the range of ports communicating RTP.
The difference of (RTP Start Port) - (RTP End Port) should be 90 or greater.
If this is less than 90, a port outside the range may be used.
Settings 1 - 65535
Default values 31000

Aiphone IX-DVF Specifications

General

Resolution	720p
Video Compression	H.264
Ingress Protection	IP65
Vandal Resistance	IK08
Operating Voltage	48 VDC (PoE)
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-40° to 140°F (-40° to 60°C)
Communication	IP
Call Tone	Chime
