Aiphone IX-DVF Web Setting Manual

77
Configuring the Station
■ Select Profile [H.264 / AVC]
■ I-picture interval [H.264/AVC]♦
■ Bit rate [kbps] [H.264 / AVC]
■ Select Quality [Motion-JPEG]
■ RTP Start Port♦
■ RTP End Port♦
Description Configure the profile for H.264 / AVC.
Settings • Baseline
• Main
• High
Default values Main
Description Choose the intervals for transmitting pictures of H.264 / AVC.
Settings 1 - 100
Default values 10
Description Choose the bit rate of H.264 / AVC.
Settings 32, 64, 128, 256, 384, 512, 768, 1024, 2048, 4096, 8192 kbps
Default values 2048 kbps
Note
• The bit rate may be lower than the set value depending on the video being sent, the number of recipient stations, and the
network environment.
Description Choose the picture quality of Motion-JPEG.
Settings 1 (Low) - 10 (High)
Default values 6
Description Configure the range of ports communicating RTP.
The difference of (RTP Start Port) - (RTP End Port) should be 10 or greater.
If this is less than 10, a port outside the range may be used.
Settings 1 - 65534
Default values 32000
Description Configure the range of ports communicating RTP.
The difference of (RTP Start Port) - (RTP End Port) should be 10 or greater.
If this is less than 10, a port outside the range may be used.
Settings 1 - 65535
Default values 33000

Aiphone IX-DVF Specifications

General

Resolution	720p
Video Compression	H.264
Ingress Protection	IP65
Vandal Resistance	IK08
Operating Voltage	48 VDC (PoE)
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-40° to 140°F (-40° to 60°C)
Communication	IP
Call Tone	Chime
