Aiphone IX SERIES Quick Start Programming Guide

13
Door Call Destinations and Master Address Book
Door/Sub Station Call Destinations
Expand Call Settings on the left-hand menu and select Called Stations (Door/Sub Stations).
Displayed will be a row of door/sub stations that are part of the system, and columns of stations they are able to communicate
with. By default, all door/sub stations are set to call every master station. Note the Station Type for the next step.
Ensure that Group 01 (default) is selected from the
Display Settings drop-down menu at the top of the
screen.
Display Settings
Click the Update button save
the changes.
Update
Station Types: IX-DV, IX-DVF(-*), IX-DVM, IX-EA, IX-SSA(-*), IX-SS-2G, IX-RS-*
Find the cross section between the door and master
station communication will be enabled/disabled
between. By default, there will be a U in the drop-down
menu. Click this drop-down and select the Blank option.
Disabling Call-in Per Station
Station Types: IX-DB, IX-BB, IX-DA, IX-BA
Ensure that Group 10 is selected from the
Display Settings drop-down menu at the top of
the screen.
Display Settings
Click the Update button to
save the changes.
Update
Find the cross section between the door and master sta-
tion communication will be enabled/disabled between.
By default, there will be a U in the drop-down menu.
Click this drop-down and select the Blank option.
Disabling Call-in Per Station
The setting le needs to be uploaded to each station
for these settings to take e󰀨ect. Refer to page 12 for
more details on this process.
Upload:


Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
