- 15 -
*1 Contact Input Specifications
*2 Audio Output Specifications
*3 Relay Output Specifications
*4 The intercom unit can be powered by using a PoE switch or Aiphone PS-2420 power supply. In the case "PoE
PSE" output of the intercom unit is used to power other devices, IEEE802.3at compatible PoE switch must be used to
power the intercom unit.
In the case both a PoE switch and Aiphone PS-2420 power supply are used in combination to power the intercom
unit,PS-2420 can provide back-up power if the PoE power supply fails. this allows continuous recording function etc.
to continue operating.
Input method Programmable dry contact (N/O or N/C)
Level detection method
Detection time 100 msec or more
Contact resistance Make: 700 Ω or less
Break: 3 kΩ or more
Terminal short-circuit current 20 mA or less
Voltage between terminals 5 VDC or less (between open terminals)
Output impedance 600 Ω
Output audio level 300 mVrms (with 600 Ω termination)
Output method Form C dry contact (N/O or N/C)
Contact rating 24 VAC, 1 A (resistive load)
24 VDC, 1 A (resistive load)
Minimum overload (AC/DC): 100mV, 0.1mA
https://www.aiphone.net/
AIPHONE CO., LTD., NAGOYA, JAPAN
Issue Date: Feb.2019 FK2452 Ⓒ P0219 RQ 61265
