Operation
16. Technical Data
16.1 Power Unit Electrical Details
Voltage (VAC) ....................................................100 - 240
Maximum fluctuation in rated voltage (%) .................................+/- 10
Frequency (Hz) ....................................................50/60
Maximum Current (A) ...............................................0.8
Electrical data ScanX Swift
Voltage (VDC) ....................................................24
Maximum fluctuation in rated current (%) .................................+/- 10
Maximum Current (A) ...............................................1.25
Power consumption (W) .............................................<30
Duty cycle
S2 (min) ........................................................25
S6 (%) ..........................................................25
ScanX Swift Physical Characteristics
Dimensions Height Depth Width
9.2 inches (23.4 cm) 9.6 inches (24.4 cm) 8.9 inches (22.6 cm)
Weight (approximate) .........................................14.5 lbs. (6.5 kg)
Noise levels
Ready (db(A)) . ..................................................... <40
Scanning (db(A)) . ................................................... <60
General values
Medical appliance category .............................................1
Laser protection class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 (EN60825-1)
Wavelength ................................ 635 nm10 mW EN 60825-1:2006-04
Heat radiation .................................................... <40 W
Pixel size can be selected from range ...................................21 to 50 µm
Maximum Resolution (depending on plate) horizontal/vertical ................13/20 Lp/mm
Conformity Acceptance Procedure
Medical device ..................................................93/42/EEC
Barrier envelope Medical device classification ................................I
Plate Medical device classification ........................................ IIa
EMC
Conducted HF - disturbance V
1
according to IEC 61000-4-6 (V
eff
) ..................3
Radiated HF - disturbance V
1
according to IEC 61000-4-3 (V
eff
) ....................4
16.2 Ambient Conditions
Operation:
Temperature ................................. 50 to 95° F .....+10 to +35 °C
Air pressure ................................. 22 - 31 in Hg .....750 - 1060 mB
Altitude ......................................<6562 ft. ........<2000 m
Humidity ............................................. 20 to 80 %
Storage and Transport
Temperature .................................-4 to 140° F ......-20 to +60 °C
Air pressure ................................ 22 - 31 in Hg .....750 - 1060 mB
Altitude .................................... <52493 ft. .......<16000 m
Humidity ..............................................10 to 95 %
