AIREDALE DR Series - Page 26

Dry Cooler
Condensers
26 Dry Coolers Technical Manual 9308503 V2_06_2020
Technical
Mechanical Data
(1) Nominal data based on 35°C ambient and a 45/40°C Water entering / leaving. All performance data is supplied in accordance with BS EN 14511-1:2013
(2) Overall dimensions for clearance; refer to Dimensional & Installation Data, for detail.
DR40 DR50 DR55
Total Heat of Rejection DR (1) kW 41.8 53 54.4
Dimensions - Horizontal (2)
H x W x L mm 1167 x 1000 x 3560 1167 x 1000 x 3560 1167 x 1000 x 3560
Dimensions - Vertical (2)
H x W x L mm 1126 x 1167 x 3560 1205 x 1167 x 3560 1126 x 1167 x 3560
Weight
Machine kg 257 286 309
Construction
Material/Colour Galvanised Sheet Steel, Epoxy Baked Powder Paint - Light Grey (RAL 7035)
Dry Cooler Air Cooled - Copper Tube/Turbulated Aluminium Fins
Total Face Area m² 3.63 3.63 3.63
Nominal Airow m³/s 7.5 10.8 6.6
Discharge H Horizontal or -V Vertical (Please Specify at Order)
Std Fan & Motor AC EC AC
Quantity 3 3 3
Diameter mm 630 710 630
Maximum Speed rpm 895 930 895
Dry Cooler
Internal Water Volume L 23.1 23.1 43.2
Water owrate l/s 2 2.5 2.6
Pressure Drop kPa 48.5 70 32
OPTIONAL EXTRAS
EC Fan
Dimensions - Horizontal
H x W x L mm 1167 x 1000 x 3560 - 1167 x 1000 x 3560
Dimensions - Vertical
H x W x L mm 1205 x 1167 x 3560 - 1205 x 1167 x 3560
Weight
Machine kg 231 - 283
