AIREDALE DR Series - Page 27

Condensers
Dry Coolers
27
Dry Coolers Technical Manual 9308503 V2_06_2020
Technical
Mechanical Data
(1) Nominal data based on 35°C ambient and a 45/40°C Water entering/leaving. All performance data is supplied in accordance with BS EN 14511-1:2013
(2) Overall dimensions for clearance; refer to Dimensional & Installation Data, for detail.
DR75 DR70 DR95
Total Heat of Rejection DR (1) kW 72 73.7 97.4
Dimensions - Horizontal (2)
H x W x L mm 1167 x 1000 x 3560 1167 x 1000 x 4644 1167 x 1000 x 4644
Dimensions - Vertical (2)
H x W x L mm 1205 x 1167 x 3560 1126 x 1167 x 4644 1205 x 1167 x 4644
Weight
Machine kg 338 408 447
Construction
Material/Colour Galvanised Sheet Steel, Epoxy Baked Powder Paint - Light Grey (RAL 7035)
Dry Cooler Air Cooled - Copper Tube/Turbulated Aluminium Fins
Total Face Area m² 3.63 4.8 4.8
Nominal Airow m³/s 9.3 8.7 12.4
Discharge H Horizontal or -V Vertical (Please Specify at Order)
Std Fan & Motor EC AC EC
Quantity 3 4 4
Diameter mm 710 630 710
Maximum Speed rpm 930 895 930
Dry Cooler
Internal Water Volume L 43.2 55.9 55.9
Water owrate l/s 3.4 3.5 4.6
Pressure Drop kPa 53 62 94
OPTIONAL EXTRAS
EC Fan
Dimensions – Horizontal
H x W x L mm - 1167 x 1000 x 4644 -
Dimensions – Vertical
H x W x L mm - 1205 x 1167 x 4644 -
Weight
Machine kg - 373 -
