18 Chapter 3
VOC SETUP
This menu item applies to TSI probes that measure Volatile Organic
Compounds (VOC). Refer to the manual included with VOC probe
Models 984, 985, 986 and 987 for information on usage and setup.
ACTUAL/STANDARD SETUP
Choose Actual/Standard measurements and parameters in the Act/Std
Setup menu. The Model TA465 measures the actual barometric
pressure using an internal sensor. The temperature source can be
entered manually or taken from a probe that measures temperature
(plug in probe or thermocouple).
For more information on Actual and Standard conditions, refer to
Application Note AF-109.
MENU
Zero Press
Display Setup
Settings
Flow Setup
VOC Setup
Actual/Std Setup
Data Logging
Zero CO
Applications
Calibration
Bluetooth Functions
ACTUAL/STD SETUP
Setting Standard
Temp source Entered
TEMP SOURCE
Entered Temp 70F
Probe
Thermocouple 1
Thermocouple 2
To Next Page
