Airflow TA465 - View Samples

26 Chapter 3
Use the  and  arrow keys to view statistics of all the
measurement parameters stored in a Test ID.
TEST 001
Pressure
Avg 1.739 in. H2O
Min 1.665 in. H2O
Max 1.812 in. H2O
# Samples 9
10/31/08 07:01:39 AM
PRINT
TEST 001
Temperature
Avg 78.2 F
Min 78.1 F
Max 78.3 F
# Samples 9
10/31/08 07:01:39 AM
PRINT
TEST 001
%RH
Avg 12.2 %RH
Min 11.1 %RH
Max 12.9 %RH
# Samples 9
10/31/08 07:01:39 AM
PRINT
Example: TEST 001 has 9 samples, each sample consists of a
pressure, temperature, and relative humidity reading. Use the <
or > keys to view statistics of each measurement parameter.
The TA465 can send this data to the optional Model 8934
wireless printer or PC capable of Bluetooth communications. To
use the PRINT command, Bluetooth communications must be
established between the TA465 and the Model 8934 wireless
printer or PC set up with Bluetooth communications.
View Samples
VIEW DATA
Choose Test Test 001
View Stats
View Samples
Print Test
