2644 Installation Instructions 6
ALTERNATE ECU MOUNTING CONFIGURATIONS
7
1
In case there is not enough room for
the recommended mounting of
the
ECU Mounting Bracket, additional
mounting holes are provided for
alternate orientations. Two options
are shown below.
2
Use the provided additional 3/8"-16 x 1"
Carriage Bolts and 3/8"-16 Hex Head
Flange Nylock Nuts to mount the ECU
Mounting Bracket.
OPTION A
OPTION B
