firestoneairide.com3
INSTALL THE ECU
2
DO NOT OVER TIGHTEN MOUNTING BOLTS AND NUTS ON THE ECU.
TOO MUCH TORQUE CAN CRACK THE PLASTIC FEET ON THE ECU.
Fasteners included in Air Command Kit
1
Mount the ECU to the hole locations in
the Compressor Plate using the supplied
fasteners. DO NOT OVERTIGHTEN.
3093 10-32 x 3/4” MACHINE SCREW
3086 #10 FLAT WASHER
3088 10-32 NYLOCK NUT
9961 ECU
3086 #10 FLAT WASHER
MOUNTING
HOLES
TOP VIEW
9961 ECU
