930 Installation Instructions 2
PARTS
Compare the parts below to your kit. Assure you have all pieces, and organize them for an easier installation.
MAIN KIT CONTENTS
PT # 9965
The 9961 ECU and
9962 Wire Harness
are packaged
inside one box
under the 9965
part number.
PT # 9961
x 1 ECU
PT # 9523
x 1
AIR COMPRESSOR
KIT
PT # 9962
x 1 WIRE HARNESS
PT # 9415
x 1
AIR TUBING
(22 FEET)
A21-760-2930 HARDWARE PACK
PT # 3087
x 4
10-32 x 1"
MACHINE SCREW
PT # 3093
x 2
10-32 x 3/4"
MACHINE SCREW
PT # 3086
x 10 #10 FLAT WASHER
PT # 3088
x 6 10-32 NYLOCK NUT
PT # 3421
x 1
10-16 x 3/4"
SELF-TAPPING
SCREW
PT # 9483
x 1
INFLATION VALVE
MOUNTING
BRACKET
PT # 3055
x 1
1/8 NPT PUSH-
TO-CONNECT
STRAIGHT FITTING
PT # 3025
1/4 PUSH-
TO-CONNECT TEE
PT # 3032
x 2
INFLATION VALVE
AND VALVE CAP
ASSEMBLY
PT # 9488
PT # 0899
PT # 9036
x 4 LARGE NYLON TIE x 2 THERMAL SLEEVE x 15 RED NYLON TIE
A24-760-2644 COMPRESSOR AND ECU MOUNTING KIT
KIT # 2644
x 1
DUAL PATH MOUNTING KIT
The parts list for this kit is in the Mounting Kit
Manual included at the end of this Manual.
