9523 AIR COMPRESSOR
3055 1/8 NPT PUSH-TO-CONNECT
STRAIGHT FITTING
Tighten to engage two threads
of thread lock.
PRE-INSTALLED
CHECK VALVE
AIR FITTING
PREPARE THE AIR COMPRESSOR
1
NOTE: Air compressor can be mounted facing any direction.
1
Install 1/8 NPT Push-to-Connect
Straight Fitting on the Check Valve.
2
Install Barbed Air Fitting in Inlet Port
of the Compressor from Air
Compressor Kit.
To Next Page
