6. Configuration
AirLive SC-300W User’s Manual
- DHCP IPv4/IPv6: DHCP for IPv6 enables the DHCP server to pass the configuration
parameters (e.g. the IPv6 network addressed) to the IPv6 nodes, which offers the
capability of automatic allocation of reusable network addresses and additional
configuration flexibility. Select this option if your network supports DHCP IPv6
protocol. When the camera starts up, it will be assigned an IP address from the
DHCP server automatically.
- Static IPv4/IPv6: Select this option to assign the IP address to the camera directly.
You can use “AirLive IP Wizard II” to obtain the related setting values.
Enter the IP address of the camera. The default setting is
Enter the Subnet Mask of the camera. The default setting
Enter the Default Gateway of the camera. The default
setting is 192.168.1.254.
DNS (Domain Name System) translates domain names
into IP addresses. Enter the Primary and Secondary DNS
provided by ISP.
The default RTSP Port (Real Time Streaming Protocol) is
RTP (Real-time Transport Protocol) is a data transfer
protocol defined to deliver live media to the clients at the
same time, which defines the transmission of video and
audio files in real time for Internet applications. The default
RTP Data Port is 5556.
Enable Multicast: Select this option to enable the multicast function of the camera.
Complete the following settings so that you can deliver information from your camera
to multi receivers.
- Multicast Group Address: Assign a category of IP addresses to receive the
information from the camera.
- Multicast Video Port: Assign a multicast port for video in the text box. The default
port is 5560.
- Multicast RTCP Video Port: Assign a multicast port for RTCP (real-time transport
control protocol) video in the text box. The default port is 5561.
- Multicast Audio Port: Assign a multicast port for audio in the text box. The default
port is 5562.
