AIRMAC T20D - 415 V Oil Free Compressor Components

Instruction Manual
Airmac Air Compressors
2019-06-07
© Glenco Air & Power Pty Ltd
8
Item
Description
Item
Description
1
Compressor Pump
9
Pallet Foot Mount
2
Air Filter
10
Non-Return Valve
3
Crankcase Breather
11
Unloading Line
4
Electric Motor
12
Safety Valve (Behind Item 15)
5
Motor Position Adjustor
13
Drain Valve
6
Air Receiver Tank
14
Discharge Outlet Valve
7
Air Receiver Tank Nameplate
15
Air Receiver Pressure Gauge
8
V-Belt Drive Guard
16
Pressure Switch
Figure 2-5 415 Volt Oil Free Air Compressor
