EXPLODED VIEWS AND SPARE PARTS LISTS
SM PNXDCI 1-A.1 GB
14.7 Indoor Unit: PNX 18 DCI
No. PN Description Quantity
1 465720126 ASilk-ScreenGrillAAssy./PNX50/60/72AIRWE 1
1 465720136 ASilk-ScreenGrillAAssy./PNX50/60/72Electra 1
2 452919800 Filter 2
3 4518113 AIR FILTER ASSY 1
4 465020046 Front Frame/PNX-18 1
5 465340035 Screw Cover/PNX-18 3
6 453134600 Evaporator Assy. 1
7 452917300 Air outlet 1
8 4518664 Drain hose 1
9 452917500 Horizontal flap A 1
9 452917600 Horizontal flap B 1
10 452930700 Vertical flap A 12
10 452918200 Vertical flap B 2
11 4518662 Bearing assy fan 1
12 453024900 Impeller fan 1
13 453053800 Base assy./WNG18 1
14 452920100 Mount bracket/WNG-18 1
15 452919400 Joint/Unit housing 1
16 453024500R PG PG Motor 1
17 452918800 Cover/motor 1
18 453050200 STEP MOTOR A 1
18 453050300 STEP MOTOR B 1
20 4519147 Power Cord Clip 1
21 467300068R Display Board /PNX 25/35 1
22 452919100 Support/sensor 1
22 4516263 SENSOR BASE 1
23 453030600R WNG Indoor DC Inverter Controller 1
24 438082 Thermistor Indoor 1
25 467400025 Indoor Air Inlet Temperature 650mm 1
26 465340036 Terminal Cover/PNX-18 1
27 4524963 Electrostatic Filter 1
29 467240005 Remote controller Assy with batteries 1
30 4518651 Cover Side Motor 1
31 453057900 Gear BOX ASSY 1
34 452918700 Support/horizontal louver 2
36 4518657 TUBE LOCK 1
38 4524967 IONIZER WIRE A 1
38 453109300 Wire UL100726AWG/Ionizer 1
39 467430000 Power Supply Unit /Ionizer 1
40 467480001 Ionizer/WNG NWNG SERIES 1
41 465160008 A Air Inlet Frame A/PNX-18 1
