CONTROL SYSTEM
SM PNXDCI 1-A.1 GB
Model dependent parameters for GC 24 / 30
Compressor Parameters Value
MinOFFTime 3
MinOnTime 3
MaxCTT1 90
MaxCTT2 90
MinSpeedAsCTT1 26
MinSpeedAsCTT2 26
MaxSpeedC 75
MaxSpeedH 95
Step1RPS 40
Step2RPS 60
Step3RPS 75
NormAcc (sec/RPS) 1
NormDec (sec/RPS) 1
Down1(Sec/RPS) 12
Down2 (Sec/RPS) 7
DeiceAcc (Sec/RPS) 0.2
DeiceDec (Sec/RPS) 0.5
EEV Parameters Value
NormEEVRate 30
EEVCompOFFOpen 200
EEVCompOFFTime 60
EEVMaxOpen 500
EEVMinOperOpenC 60
EEVMaxOperOpenC 500
EEVMinOperOpenH 70
EEVMaxOperOpenH 500
EEVMinOperOpenHInIDU 60
EEVMaxOperOpenHInIDU 140
EEVIDUOFFOpen 130
EEVMoveSteps 20
EEVTConstC 30
EEVTConstH 30
BlncTimTrnsStC 1
BlncTimStdyStC 1
BlncTimTrnsStH 1
BlncTimStdyStH 1
CompOffTimToTrnsSt 20
No. Name SingleDCI-72 Z
1 MinFreqC 15
2 MaxFreqC 70
3 MinFreqH 15
4 MaxFreqH 90
7 Step1Freq 35
8 Step2Freq 55
9 Step3Freq 90
10 OFMinRPM 8
11 OFMaxRPM 90
12 NightRPM 65
13 OFNNoiseMaxRPM 78
14 CTTOH1 90
15 CTTOH2 95
16 CTTOH3 100
17 CTTOH4 105
18 CCROC1 12.5
19 CCROC2 13.3
20 CCROC3 14.1
21 CCROC4 14.9
22 ProtFreqLimit 60
23 EEVMinOperOpenC 50
24 EEVMaxOperOpenC 480
25 EEVMinOperOpenH 50
26 EEVMaxOperOpenH 480
27 HeaterDisableFlag 0
28 HST Enable 1
29 OATLimitC 24
30 OATLimit1H 6
31 OATLimit2H 15
32 MaxFreqAsOATC 60
33 MaxFreqAsOAT1H 85
34 MaxFreqAsOAT2H 75
35 NormAccel 1
36 NormDecel 1
Model dependent parameters for GC 24 Z
