Airwell VAR 9 User Manual

2-1
PRODUCT DATA SHEET
SM VAR 1-A.1 GB
Model (Indoor & Outdoor) Unit VAR 9 ST/RH
Characteristics Units Cooling
Heating
(by heater)
Capacity
(1)
Btu/hr 8530 -
kW 2.5 -
Power input
(1)
kW 0.92 2x0.75
COP
(1)
W/W 2.61 -
Energy efficiency class A -
Power supply V/ Ph /Hz 230 / 50 / 1
Rated current A 4.2 6.7
Starting current A 18.7
Circuit breaker rating A 10
INDOOR
Fan type & quantity Centrifugal x 1
Fan speeds H/ M/ L RPM 940 / 845 / 760
Air flow H/ M/ L m³/hr 400 / 360 / 315
Sound pressure level
(2)
H/ M/ L dB(A) 47 / 44 / 42
Sound power level H/ M/ L dB(A) 56 / 53 / 51
Moisture removal L/hr 1
Condensate drain tube I.D mm 9
Dimensions W/ H / D mm 1110 382 240
Weight kg 42
Package dimensions W/ H / D mm 1160 460 335
Packaged weight kg 45
Units per pallet Units 12
Stacking height Units 2
OUTDOOR
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Centrifugal x 1
Fan speeds H RPM 1300
Air flow H m³/hr 358
Refrigerant type R410A
Refrigerant charge kg 0.66
Operation control type Touch panel
Heating elements kW 2x0.75
Others
(1)
Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
(2)
Sound pressure level measured at 1-meter distance from unit.
2. PRODUCT DATA SHEET
2.1 Model: VAR 9 ST/RH
