KiPro Mini v4.2 www.aja.com
90
Panel User Interface
3-line LCD display, with dedicated buttons (15)
Storage
Compact Flash (CF) media, 2 slots with Ejectors and Slot LEDs showing media state. Go to the AJA
website for the latest list of qualified CF cards:
http://www.aja.com/pdf/KiProMini_qualifiedCF_cards.pdf
Timecode
LTC timecode input via BNC
SDI embedded RP188 timecode
Control
LANC Loop (2 LANC connectors)
Temperature
Operating Temperature Range: 5C to 40C
Safe Storage Temperature Range (power OFF): -20C to 60C
Power
Voltage:
100-240 VAC (to supplied AC Adapter)
12 Vdc to power connector input on bottom of unit:
12 Vdc minimum
18 Vdc maximum
Current:
1.5A (maximum)
Power:
18W (at 12Vdc), 15W typical
