OG-UDC 3G-SDI Up, Down, Cross-Converter v1.0 30 www.aja.com
Reference Input
• Supported reference video inputs include:
• 1080i tri-level sync
• 1080p tri-level sync
• 720p tri-level sync
• 625i Color Black
• 525i Color Black
• 75-ohm terminating
HDMI Output
• 10-bit HDMI v1.4a
Audio I/O
• 16-Channel embedded SDI audio input
• 16-Channel embedded SDI audio output
• 8-Channel HDMI audio output
• Balanced analog audio outputs, 2x 3-Pin terminal block connectors
User Controls
• External DIP switch
• openGear DashBoard network control software via Windows, macOS or Linux
Size
• openGear standard form factor, front slot and rear card. Two slots required for
each card.
Weight
• 0.5 lb (0.3 kg)
Power
• openGear frame compatible, 7.0 watts max per card
Environment
• Safe Operating Temperature: 0 to 40 C (32 to 104 F)
• Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
• Operating Relative Humidity: 10-90% noncondensing
• Operating Altitude: <3,000 meters (<10,000 feet)
