Appendix A – Specifications
OG-UDC Tech Specs
Video Formats
• (2K) 2048 x 1080p
• (2K) 2048 x 1080PsF
• (HD) 1920 x 1080p
• (HD) 1920 x 1080PsF
• (HD) 1920 x 1080i
• (HD) 1280 x 720p
• (SD) 720 x 625i
• (SD) 720 x 576i
• (SD) 720 x 480i
Video Input Digital
• 1x 3G-SDI BNC, SMPTE-259/292/372/424
• (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
• (2K) 2048 x 1080PsF 23.98, 24, 25, 29.97, 30
• (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
• (HD) 1920 x 1080PsF 23.98, 24, 25, 29.97, 30
• (HD) 1920 x 1080i 50, 59.94, 60
• (HD) 1280 x 720p 50, 59.94, 60
• (SD) 720 x 576i 50, 59.94, 60
Video Output Digital
• 1x 3G-SDI BNC, SMPTE-259/292/372/424
• (HD) 1080p 23.98 (for 23.98 video inputs)
• (HD) 1080p 24 (for 24 video inputs)
• (HD) 1080p 25 (for 50 video inputs)
• (HD) 1080p 29.97 (for 59.94 video inputs)
• (HD) 1080p 30 (for 60 video inputs)
• (HD) 1080p 50 (for 50 video inputs)
• (HD) 1080p 59.94 (for 23.98, 59.94 video inputs)
• (HD) 1080p 60 (for 24, 30 or 60 video inputs)
• (HD) 1080PsF 23.98 (for 23.98 video inputs)
• (HD) 1080PsF 24 (for 24 video inputs)
• (HD) 1080PsF 25 (for 50 video inputs)
• (HD) 1080PsF 29.97 (for 59.94 video inputs)
• (HD) 1080Psf 30 (for 30 or 60 video inputs)
• (HD) 1080i 59.94 (for 23.98, or 59.94 video inputs)
• (HD) 1080i 60 (for 24, 30, or 60 video inputs)
• (HD) 1080i 50 (for 25 or 50 video inputs)
• (HD) 720p 50 (for 50 video inputs)
• (HD) 720p 59.94 (for 23.98, 59.94 video inputs)
• (HD) 720p 60 (for 24, 30, or 60 video inputs)
• (SD) 625i 50 (for 25 or 50 fps video inputs)
• (SD) 525i 59.94 (for 23.98 or 59.94 video inputs)
