Modulation of the radio signal GFSK
Radio signal range Up to 1,200 m (any obstacles absent)
Socket for connecting wire detectors Yes, NC
Power supply 1 battery CR123A, 3 V
Battery life Up to 5 years
Installation method Indoors
Operating temperature range From -10°С to +40°С
Operating humidity Up to 75%
Dimensions Ø 20 × 90 mm
Weight 29 g
Certification
Security Grade 2, Environmental Class II in
conformity with the requirements of EN 50131-1,
EN 50131-2-6, CLC/TS-50131-2-8, EN 50131-5-3
Complete Set
Warranty
Warranty for the “AJAX SYSTEMS MANUFACTURING” LIMITED LIABILITY
COMPANY products is valid for 2 years after the purchase and does not apply to
1. DoorProtect Plus
2. SmartBracket mounting panel
3. Battery CR123A (pre-installed)
4. Big magnet
5. Small magnet
6. Outside-mounted terminal clamp
7. Installation kit
8. Quick Start Guide
