Akai EWV2000 User Manual

Features
WARNING
This equipment generates and uses radio frequency energy and if
not installed and used properly, that is, in strict accordance with the
manufacturer's instructions, may cause interference to radio and tele
vision reception. It has been type tested and found to comply with the
limits for a Class B computing device in accordance with the specifica
tions in Subpart J of Part 15 FCC Rules, which are designed to provide
reasonable protection against such interference in a residential installa
tion. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment dose cause interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the in
terference by one or more of the following measures:
Reorient the receiving antenna
Relocate the computer with respect to the receiver
Move the computer away from the receiver
Plug the computer into a different outlet so that computer and re
ceiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced
radio/television technician for additional suggestions. The user may
find the following booklet prepared by the Federal Communications
Commission helpful:
"How to Identify and Resolve Radio—TV Interference Prob-
)ems"'
is booklet is available from the U.S. Government Printing
, Washington, DC 20402, Stock No. 004-000-00345-4.
We greatly appreciate your purchase of the AKAIEWV2000 EWI &
EVI Sound Module.
The EWV2000 is a sound module exclusively for use with the
EWI 1000 (woodwind type) or EVI 1000 (brass/valve type) wind
instrument style controller.
This manual includes detailed explanations of operations, etc. de
signed to show you how to use the superior functions of the
EWV2000 to their fullest extent.
• The EWV2000 is a 2-system type "analog synthesizer module"
with 2 VCOs, 2 VCFs, 2 VC As, and 4 EGs.
• The EVW2000 can be used to produce a rich variety of expressions
with the breath sensor, lip sensor, and touch sensor of the
EWI 1000 or EVI 1000 wind instrument controller, including rise
and fall of the tone, strength of the tone, pulse width modulation,
clarity of timbre, vibration effects, and glide effects.
• Using the two synthesizers makes it possible to create a variety of
voices and play in a variety of ways, for example by producing two
different sounds simultaneously or slightly varying the attack and
sustain for the two sources.
• The EWV2000 is equipped with 64 built-in memory banks, and the
voice in each bank can be named.
• MIDI OUT jacks, so an external MIDI sound source or sampler
can also be played from the EWI1000 or EVI1000.
• Audio signals can be input from an external component, for exam
ple a sampler, and mixed with the synthesized sound, and voices
and expressions can be created using the sampled sound.
• 16-character LCD dialogue-style easy operation improves operabil-
ity and ease of verification when editing.
• Equipped with tape interface for external storage of memory files,
so voice data can be recorded on cassette tapes.
• 64 ready-playable voices are stored in the memory banks upon
shipment. These voices can easily be used as a base for creating
your own voices.
• Polyphonic play of up to 4 sounds is possible on an external MIDI-
compatible sound source using the programmed polyphonic chord
patterns.
Table of Contents
Before Using 1
Features/Table of Contents 2
Part Names and Functions 3
Control panel 3—4
Rear panel 5
Connections 6
Connecting to the EWI1000 or EVI1000..................... 6
Connecting to an external sound source 6
Connecting to external components . 7
How the EWV2000 Works 8
What is a "synthesizer"? 8
2-synthesizer configuration 9
oration 11
aving the pre-programmed voice data 11
Verifying the saved voice data 12
Loading the voice data 13
Playing the pre-programmed voice data 14
Creating Sounds 17'
Setting to the EDIT mode ... 17
EWV2000 parameter table 18
Mastering the basics of sound creation 26
Trigger 30
Using the BACKWARD button 32
Variations in sounds using the SYNCHRONIZE ON
setting 33
WAVE ENV FM for producing metallic sounds 33
Labeling voices 34
Storing voice data in the memory banks 34
Playing External Sound Sources with the MIDI Terminals 36
Data Sent from MIDI OUT 36
Connections 36
Setting Procedures 36
Ways of Using the EXT IN Jack to Enhance Expression 37
Functions for which the Polyphonic Chord Patterns can be
Programmed 38
Pre-programmed Sample Chord Patterns 41
Parameter copy function 43
Polyphonic Chord/Data Sheet 44
Specifications 45
MIDI Implementation Chart 47
