Table of contents and cautionary notes
This is your Akai Digital Integrated
Amplifier
This Akai high quality digital integrated amplifier incorpo-
rates an optical signal transfer system, 4 times over sam-
pling digital filters, independent type left and right D/A
converters, and a digital noise reducing construction. With
an original zero drive circuit and 3 pole servo, this high
power open loop power amplifier provides accurate digital
source reproduction. To enjoy the Akai digital integrated
amplifier properly, please read this operator’s manual thor-
oughly.
Table of contents
Table of contents and cautionary notes ............. 1-2
Controls (Front panel) .......... 0.00 cece cece ee eee eee 3
Controls (Rear panel)............0 0 cece eee e cee eee eens 4
Making the right connections ...................... 5-6
Digital component connections.....................00. 7
Graphic equalizer connections.....................00. 8
Analog source playback ................00cc ce cee eee 9
Digital source playback............ 0... cece eee eee eee 10
Operation details... 0.0.0.0... ccc eee eee ee 11-12
Recording sc. .c4 hits toa ni ane geet ee eens 13-15
Analog/Digital source recording ................... 13
Digital source recording............. cc ccc eee eee 14
Tape Dubbing ......... 0... cece eee eee 15
Problem? Let’s check first ..................0... 16-17
SPeCiiCations'.< 4 pisces oiaiar ga wtine os davhedes en 18
——
WARNING
To prevent fire or shock hazard, do not expose
this appliance to rain or moisture.
1-En
Power requirements
Power requirements for electrical equipment differ
from area to area. Please ensure that your machine
meets the power requirements in your area.
If in doubt, consult a qualified electrician.
120 V, 60 Hz for USA and Canada
220 V, 50 Hz for Europe except UK
240 V, 50 Hz for UK and Australia
110 V/120 V/220 V/240 V, 50 Hz/60 Hz convertible
for other countries.
Voltage conversion
(Not on all models)
Models for Canada, USA, Europe, UK and Australia
are not equipped with this facility. Each unit is
preset at the factory according to its destination, but
some units can be adjusted to 110 V, 120 V, 220 V
or 240 V as required.
If your unit’s voltage can be converted:
Before connecting the power cord, turn the VOL-
TAGE SELECTOR located on the rear panel with a
screwdriver until the correct voltage is indicated.
ay ae
Hl —~©@ -@@ 4
5 OO -@O
©
©
@ -©® -@©®
-@®-0€
see ee
“OO -@O
VOLTAGE SELECTOR
2-En
