AKG C 520 - C 520; C 520 L

Refer to fig. 1
on page 13.
1.5 C 520
1.6 C 520 L
3 Adjustable, detachable 5-inch (125-mm)
gooseneck for precise microphone position-
ing.
4 Removable microphone arm holder for placing
the microphone to the left or right of your
mouth.
5 Microphone cable strain relief.
• For 9 to 52 V universal phantom power.
• 10-ft. (3-m) plug-in connecting cable with
phantom power adapter with integrated 3-pin
XLR connector and switchable bass rolloff (6)
(-4 dB at 100 Hz).
Fig. 1a: Phantom power adapter
with bass rolloff switch (6).
• For use with the B 29 L battery power supply,
MPA V L phantom power adapter, or PT 40 or
PT 400 transmitters.
• 5-ft. (1.5-m) plug-in connecting cable with 3-
pin mini XLR connectors.
1 Description
14
AKG C 520/C 520 L

