HT 40 PRO/FLEXX
25
7 Specifications
HT 40 PRO and HT 40 FLEXX
Carrier frequency range: 660 to 865 MHz; HT 40 FLEXX: 3 selectable frequencies
Modulation: FM
Audio bandwidth: 65 to 20,000 Hz
Frequency stability(-10°C to +50°C): ±15 kHz
Rated deviation: 15 kHz
T.H.D. at 1 kHz: typ. 0.8%
Compander: Yes
Signal/noise ratio: typ. 110 dB(A)
RF output: 10 mW
Current consumption: typ. 70 mA
Power requirement: 1 x 1.5 V AA size battery (LR 6 to IEC 86-L)
Battery life: typ. 31 hours (for 2200 mAh)
Size: 229 x 53 x 53 mm (9 x 2.1 x 2.1 in.)
Net weight: 214 g (7.6 oz.)
This product conforms to the standards listed in the Declaration of Conformity. To order a free copy of the Declaration of Con-
formity, visit http://www.akg.com or contact sales@akg.com.
