AKG P170 - Technical data

20 P170
Technical data
Type: 1/2" diaphragm, true condenser pressure-gradient microphone
Polar pattern: cardioid
Sensitivity: 15 mV/Pa
(
-36.5 dBV)
Frequency response: 20 Hz to 20 kHz
(see frequency response trace)
Electrical impedance:
≤
200 ohms
Recommended load impedance:
≥
1000 ohms
Equivalent noise level to IEC 60268-4:
19 dB(A)
Signal to noise: 75 dB(A) re 1 Pa
Max. SPL for 0.5% THD: 135 / 155 dB SPL (0 / -20 dB)
Temperature range:
-10 °C to
+60 °C (14 °F -
140 °F)
Phantom powering: 48 V ±4 V to IEC 61938
Current consumption:
≤
3 m
A
Connector: 3-pin XLR (pin 2 hot)
Diameter:
22 mm (0.86 in.)
Length:
160 mm (6.3 in.)
Net weight: 130 g (4.59 oz)
Preattenuation pad: -20 dB
Frequency Response Polar Diagram
This product corresponds to the standards stated in the Declaration of Conformity. You can request the
Declaration of Conformity by e-mail from sales@akg.com.
