AKG P820 - Technical Specifications; Microphone Specifications; Remote Control Unit Specifications

32 P820
Technical data
Type: 1" dual-diaphragm, tube microphone
Polar pattern: 9 selectable polar patterns (selectable on remote control unit)
Sensitivity:
(cardioid)
20 mV/Pa
(
-34 dBV)
Frequency response:
20 Hz to 20 kHz
(see frequency response trace)
Electrical impedance:
≤
200 ohms
Recommended load impedance:
≥
1000 ohms
Equivalent noise level to IEC 60268-4:
16 dB(A)
Signal to noise:
78 dB(A) re 1 Pa
Max. SPL for 0.5% THD:
135 / 155 dB SPL
(0 / -20 dB)
Temperature range:
-10 °C to +60 °C (14 °F -
140 °F)
Phantom powering: via Remote Control Unit only
Connector: dedicated 7-pin male XLR
Diameter:
54 mm (2.13 in.)
Length:
212 mm (8.3 in.)
Net weight:
765 g (27 oz.)
Bass cut pad:
80 Hz,
12 dB/octave (switchable on Remote Control Unit)
Preattenuation pad:
-20 dB (switchable on Remote Control Unit)
A
udio &control input connector:
dedicated 7-pin female XLR
A
udio output connector: standard 3-pin male XLR (balanced, pin 2 hot)
Polar pattern selector: 9-position detented rotary switch
Bass cut filter switch: 2-position toggle switch
Preattenuation switch: 2-position toggle switch
Power voltage:
210-240 VAC or 110-120 VAC, selectable
Primary fuse:
125 m
A
/
250 V slow-blow
7 Technical data
Microphone
Remote Control Unit
