Akiles Cardmac Pro - Sub-Accumulated Counting Reset; Check the Total Accumulated Cards; Adjust the Name Card Size; Select the Cutting Column

12
c. When the cut card appears as follows, select [-] key (Select from -2.0mm to +2.0mm)
Visible Edge
Sub-accumulated Counting Reset
1) When [Set Parameter] key is pressed nine times, the LCD panel will show:
2) Press the [-] key to reset the sub-accumulated counting.
Check the Total Accumulated Cards
1) When [Set Parameter] key is pressed eight times, the LCD panel will show:
2) Press [Mode changeover] key to return to the standby state.
Adjust The Name Card Size
1) When [Set Parameter] key is pressed ten times, the LCD panel will show:
2) Select it (85mm, 89mm, 90mm, 95mm) via [+] or [-] key.
3) Press the [Mode changeover] key to return to the standby state.
Select The Cutting Column
1) When the [Set Parameter[ key is pressed twelve times, the LCD will show:
Content
Sub-accumulated cards:
XXXX
Accumulated cards:
XXXXXX
Slitting width:
XX
Cutting Columns:
X
