Status Messages – Poll / Response
Message type 0x04 – pCode Version Poll
Header (29 bits) 2 22 11 00 0
8........43.....65..... 87......0
1100011101111 [ A ] [ B ]
3 bits, Priority 6 (110)
2 bits, 00
8 bits, 0xEF
[A] = 8 bits, Target (AB node address)
[B] = 8 bits, Source (Integrator node address)
Data length – 1 byte
Data byte 0
bit 7......0
00000100
8 bits, Message type 0x04
Example – 18EF8005 [1] 04
This message requests pCode version information from the AB unit at CAN node address ‘0x80’ to be sent to the Integrator unit at
CAN node address ‘0x05’.
Message type 0x05 – Config Version Poll
Header (29 bits) 2 22 11 00 0
8........43......65......87......... 0
1100011101111 [ A ] [ B ]
3 bits, Priority 6 (110)
2 bits, 00
8 bits, 0xEF
[A] = 8 bits, Target (AB node address)
[B] = 8 bits, Source (Integrator node address)
Data length – 1 byte
Data byte 0
bit 7......0
00000101
8 bits, Message type 0x05
Example – 18EF8005 [1] 05
This message requests config version information from the AB unit at CAN node address ‘0x80’ to be sent to the Integrator unit at
CAN node address ‘0x05’.
