● LED Color: it can support three colors: Red, Green, Blue.
● LED Display Mode: to set up the different blink frequencies.
7.3.Set up LED Display from HTTP URL
Akuvox door phones support to use HTTP URL to remote control the LED display
status. You can enter the HTTP URL in the browser to manage the LED color and
frequency.
Parameters Set-up:
● HTTP URL format:
http://PhoneIP/fcgi/do?action=LedAction&State=1&Color=1&Mode=2500
● Status: 1=Idle; 2=OffLine; 3=Calling; 4=Talking; 5=Receiving; Color:
1=Green; 2=Blue; 3=Red; Mode: 0=Always On; 1=Always Off;
500/1000/1500/2000/25000/3000
