Step 2: Main Unit Installaon
A
Hang R20A on the wall-mounting bracket with rope for easier
installation.
B
Make wires go through the wiring cover and connect them to the
corresponding (for details, refer to "Wiring Interface").
R20A
Wall-mounng Installaon
C
Fasten the wiring cover with four M2.5x6 crosshead screws.
Fix four wall-mounting screws on the back of R20A.
