BOX CONTENTS & MAIN COMPONENTS
Box Contents & Main Components
Box Contents
Main Components
Display
Wireless
Module Dock
Interface
Mains Screw Terminal
Pump Screw Terminal
Flow Switch/ Sensors /
Auxiliary Switch Screw
Terminals
Cable Strain Relief
Cable Strain Relief
Status LED
Front
Cover
Pump
Cable
Mains
Cable
Terminal
Cover
Back Case
SENSOR 1
0 S +
SENSOR 2 AUX PUMP
0 S + AB
