Reassembly - Front Cover
17
Reassembly - Front Cover
Installer
Ensure all connectors are correctly inserted before the cover is refitted.
Refit the Front Cover taking care not to trap the ribbon cable or any other wires.
Only use the supplied screws to secure the front cover. Failure to do so, can cause internal damage
to the appliance.
Carefully connect the ribbon cable Attach the front cover to the shower
