© 2019 AKW 13-012-085-17
Contents
Introduction
3
These instructions are provided to advise the minimum standards of installation and recommend the best practice for the installation.
Due to the wide variability of possible installation conditions, AKW cannot provide every solution for the installation. AKW does not
accept any liability in connection with this information or its use. This information is provided on the condition that the person receiving
it shall make their own tests to determine the suitability for their particular purpose. None of the foregoing affects your statutory rights.
Failure to install this AKW product in accordance with supplied instructions or the making
of unauthorised modifications will invalidate any warranty and may affect product safety.
Please ensure the warranty card details are filled in and returned in the envelope provided.
Alternatively visit our website and register online. www.akw-ltd.co.uk/warranty
Introduction 2-3
Product Features 2
Contents 3
User 4-9
Safety Information 4
Operating Instructio
ns 5
Volume Setting
6
Maintenance and Cleaning
7
Troubleshooting 8
Warranty 9
Installer 10-17
Main Components 11
Specification s 12
Installation Requirements 13
Disassembly 14
Fitting to wall 15
Reassembly - Bottom Cover 16
Reassembly - Front Cover 17
Plumbing 18-21
Water Requirements 18
P
lumbing Connections 19
Plumbing Entry Points 20
Check List 21
Electrical 22-25
Electrical Requirements 22-23
Electrical Entry Points 24
Connecting Waste Pump 25
Commissioning 26-34
Temperature & Mode Settings 26
Cold Water Flushing
27
Functional Checks
28
Troubleshooting For Engineers 29-31
Commissioning/in-service tests 32-33
Service Record
34
