© 2019 AKW 13-012-085-17
31
Troubleshooting for Engineers
Commissioning
Follow the disassembly instructions on page 14 to expose the inlet filter. Always isolate the electricity
supply before opening the cover.
Ensure that the electrical supply is switched off at the mains.
Ensure that the water supply is turned off.
Rinse the filter in water and once this is clean then return to the inlet housing and reassemble.
Remove the 4 screws and carefully lift off
the front cover.
Carefully lift off the front cover and
unscrew the filter.
Inlet
Filter
Cleaning the Filter-
This should only be done if you suspect reduced flow rate or water hardness build up.
