Installing the Doorbell - Replacing a Digital Doorbell
u
Turn off power to the doorbell. Remove
the existing doorbell and disconnect the
two wires.
v
Connect the two wires as shown.
INSTALLATION
IMPORTANT: Please set up the doorbell first before mounting and stay in close range with the doorbell during setup.
If you have a digital doorbell (looks similar to image at the
right), which usually plays a short musical tune, then do the
following:
Digital Adapter
w
I
nstall the digital adapter using the included
sticker to the door chime box as shown and
then go to step 4 on page 10.
Make sure
Digital is selected in the Doorchime setting,
see page 35.
