Alcad 201 Series User Manual

67
Example 2 – Video door entry installation for 2 entry points and 8 houses or flats
Special features:
One house or flat with two monitors
One house or flat with monitor and telephone
1. GENERAL LAYOUT DIAGRAM OF THE INSTALLATION
5
5
2
2
SCM-010
MVB-001
ABR-001
1
2
2
2
COAX
4+N
DIV-024
5
2
5
2
ALA-040
230 V
V
230 V
ALM-040
V
MVB-001
SCM-010
SCM-010
SCM-010
MVB-001
MVB-001
1
DIV-024
MDN-041
MPS-004
SCM-010
MVB-001
TES-001
230 V
V
ALA-040
ABR-001
COAXIAL
6+N
2
2
2
MDN-041
MPS-004
22
SECTION TABLE
Up to 100 m
1,1 mm
0,6 mm
0,25 mm
2
AWG
17
1 mm
2
COAXIAL 75 Ω
