36
FLUSH-MOUNTED BOX
MECHANICAL ASSEMBLY
4
BREAKING THE PERFORATED HOLES
The flush-mounted box has several perforated holes to
pass the cables through. Break the ones you need.
ASSEMBLING SEVERAL BOXES
Break the side walls of the flush-mounted box.
Assemble the flush-mounted boxes using the set of
separators, model CEM-001.
