Alcatel-Lucent Enterprise ALE-400 - Page 67

User manual
8AL91434ENABed01 67 /113
3.2.4 Manage wireless network
3.2.4.1 Display WLAN information
• : open the user local menu.
• WLAN Status: display information about the WLAN (access point (SSID), channel, quality, …).
3.2.4.2 Define the Wi-Fi access point to be used
• Access to the administration menu of the desk phone.
• Network
o Wireless Network Config
o Wifi config:
▪ Auto only: only the automatically configured access point is used.
▪ User only: only the manually configured access point is used.
▪ Auto & User: all defined access points are used.
3.2.4.3 Define the country where the phone is installed
• Access to the administration menu of the desk phone.
• Network
• Wireless Network Settings
• Enable IEEE 802.11d: uncheck the option.
• Enter the two-character country code.
• Validate.
• Select this icon until you see the exit icon.
• Exit the administration menu and the phone will be automatically restarted.
3.2.4.4 Open the Wi-Fi manager
• Access to the administration menu of the desk phone.
• Network
• Wireless Network Config
• User networks: saved wireless networks are listed.
Add new network
• <<Add new network>>: registering a new user network.
• Enter all SSID information: name, authentication type, ID, password, …).
• Validate.
The new network is added to the network list.
Modify network
• Select the network to modify.
• Modify
All information except the name and authentication method can be edited (the password and the
security protocol are hidden, but it is possible to enter new ones).
• Validate.
