Alcatel-Lucent 8262 User Manual

8262 DECT Handset
8AL90323ENAAed01
6 /60
 Access to personal speed dial (Long press).
LED
 Green steady: the phone is on the charger and the battery is fully charged.
 Red steady: the phone is on the charger and the battery is charging.
 Slow yellow flashing: Telephonic event such as unread message, missed call,
etc.
 Rapid yellow flashing: incoming call.
 Slow Red flashing: out of coverage.
 Rapid red flashing: low battery warning.
 Slow blue flashing: Bluetooth is activated.
 Flashing when the phone is plugged into the charger means the same as when
the phone is not plugged into the charger.
 3.5 mm jack plug for headset and maintenance.
 Short press: decrease the volume of the ring tone during an incoming call (8
steps) or decrease the volume of the earpiece or loudspeaker during a
conversation (8 steps).
 Long press: activate/deactivate the mute feature.
 Short press: increase the volume of the ring tone during an incoming call (8 steps)
or increase the volume of the earpiece or loudspeaker during a conversation (8
steps).
 Long press: activate/deactivate the loudspeaker.
 Lock/unlock the phone.
 Pull cord.
 USB socket for charging the battery and upgrading the phone.
 Emergency calls (optional).
 Back to homepage.
 Programmable keys (F1 and F2 keys).
 Long press: activate/deactivate meeting mode (ascending ringing).
Back of
the set
 Clip to hook your phone on your belt.
 Access to the battery compartment.
