1:14 IMPORTANT INFORMATION
• Always switch off the main isolating switch (12V) for the heating system when the vehicle is not in use.
• The LPG burner must not be in operation when refuelling the vehicle or when lling a xed LPG tank.
• When washing the vehicle, do not spray water directly towards the ue.
• When camping in winter conditions, ensure that the ue and exhaust air valves are kept clear of snow and ice.
• The vehicle may be heated even if the hot water boiler inside the boiler is not lled with water.
• The LPG burner and electric element may be operated simultaneously.
• Always drain the hot water tank in the heating system when there is a risk of frost and when the vehicle is not being
used. Failing to do so could lead to a risk of serious frost damage.
• Always renew the air cushion in the hot water tank after 10 days of use to create a new air cushion. This can be
done by opening the safety/drain valve on the heating system for a few seconds.
• Always maintain the proper level of glycol uid in the heating system.
• The glycol mixture should be changed every other year because certain properties such as corrosion protection
deteriorate over time.
Omitting to change the uid can result in frost damage, corrosion, bacterial growth and/or overheating.
• Sterilisation uids for water can cause harmful corrosion to the stainless structure of the heating. Always read the
data label regarding additives that are used and make sure that the system is ushed of all additives before using
the heating system.
• Be aware of hard water: Hard water is water that has a high dissolved-mineral content, particularly calcium. If the
boiler is used in a hard water area for prolonged periods, install a water lter. Hard water can lead to a build-up of
lime scale that can reduce the functionality of the system.
• Bleed the heating system, see section “1:13 bleeding the system”. Top up with more liquid if the level has fallen
after bleeding. Bleed a newly lled heating system regularly during the rst days the heating system is in operation.
NOTICE
Close the main LPG valve in the following circumstances:
• When a leak in the LPG system is suspected.
• When the vehicle is not intended to be used.
• The national legislation of the country you are in may require you to close the main LPG tap when the vehicle is
in trafc.
• When repairing the heating system.
17
GB
2. OPERATING INSTRUCTIONS FOR CONTROLPANEL
2:3 SETTINGS MENU
Launch the settings menu by pressing the MENU button. The background light comes on and those functions that can
be set are displayed. Settings that you make are automatically saved after 10 seconds. The control panel will go to
standby automatically after 30 seconds if the screen has not been touched.
1. To start the boiler, press the On/Off
button and the start-up display ap-
pears. The boiler starts with the last
selected settings. A green LED comes
on beside the On/Off button when the
panel/heating system is on.
2. To switch off the boiler, press the On/
Off button.
3020
High Efficiency
2:2 STANDBY
The heating system is switched off. The heating system is switched on.
22°C
6°C
Fri 18.30
D
C
A
L
M
I
B
E
F G H J
1 kW
+22°C
ACC
22°C
6°C
Fri 18.30
For activated functions, see section 2:9.
For the tools menu, see section 2:10.
The control panel in standby mode.
The control panel in settings menu.
CAUTION
OBSERVERA
ATTENTION
VOORZICHTIG
Do not drink any alcohol or take any drugs before or during operating the heating system and follow the safety in-
structions in this manual carefully.
NOTICE
If “Background light” is set to Dark, the display goes out when it enters standby mode, but lights up if you press the
screen. See settings in section 2:11, point 8.
A. Clock. The clock shows the day and time (if
activated). To set the clock, see under sec-
tion 2:11 point 4.
B. *Outdoor temperature.
C. Indoor temperature.
D. Circulation pump. The symbol is displayed
when the pump is in operation.
E. Automatic start of the boiler. The symbol is
displayed when the function is activated in
accordance with section 2:11 point 18.
F. Day mode. The symbol is displayed when
the function is on and turns green when
activated
G. *LPG bottle full/empty. The symbol is
displayed when the sensor on DuoCon-
trol is connected and activated. If EisEX
is installed a snowake is shown inside
the gas botle.
Green bottle = Bottle full
Red bottle = Bottle empty
H. Night mode. The symbol is displayed
when the function is on and turns green
when activated.
I. High altitude mode. The symbol ashes
if the high altitude mode is activated.
J. The symbol ashes during heat up of
*Alde Flow
(part no. 3020 161) when set in
more hot water mode.
K. 230 volt. The symbol is displayed when
230 V is connected to the boiler.
L. On/Off button. Main switch for boiler.
M. MENU button. Button for settings menu.
2:1 TURNING THE BOILER ON AND OFF
Functions marked with a (*) are accessories, which are not installed on all vehicles,
refer to the vehicle manufacturer’s instructions.
K
