6
• MEASUREMENTS / WEIGHT
Boiler height: 310 mm
Boiler depth: 340 mm
Boiler width: 510 mm
Weight: 14 kg (without uid)
Gas: Propane Butane
Output 1: 3.3 kW 3.8 kW
- Consumption: 245 g/h 275 g/h
Output 2: 5.5 kW 6.4 kW
- Consumption: 405 g/h 460 g/h
Pressure: I
3+
28-30/37 mbar I
3B/P
30 mbar
• VOLUME/PRESSURE/TEMP
Volume of liquid, radiator water: 3.5L
Volume of liquid, domestic hot water: 8.4L
Max pressure radiator water: 0.05 MPa (0.5 bar)
Max pressure domestic hot water: 0.3 MPa (3.0 bar)
System temperature (max): 80 °C.
230–240 V ~
Output element:
(2 or 3 kW)
1 x 1050 W
1 x 2100 W
12 V DC
Current consumption: 1.9 A (max)
Fuse: 3.15 A
TECHNICAL DATA
1:1 CHECKING THE HEATING SYSTEM BEFORE USE
• Check the glycol uid level in the expansion tank: the level should be approx. 1 cm above the min. line when the
system is cold. Ensure that the system is properly bled before it is put into operation.
• Check that the ue is kept free of snow and ice, as induction air enters the boiler via the ue when operated on LPG.
Also check that other objects are not obstructing or disrupting ue gases and supply air at the u.
Tip! A ue extension
(part no. 3000 320) is recommended for the roof ue for camping in winter.
• Check the air circulation. Make sure there are no obstructions preventing air circulation (convection). In order to
exploit the water-borne heating to the full, it is important that air can circulate freely under bunks, and behind back-
rests and wall-mounted cabinets. If the vehicle has a tted carpet, ensure that the carpet does not obstruct the air
supply to the convectors. It is just as important that cushions and blankets do not obstruct and prevent the ow of air
behind backrests.
1:2 THE FIRST TIME THE HEATING SYSTEM IS STARTED
• Hot water boiler: Always ush the boiler completely before using for the rst time or if it has not been used for a long
period. Then ll the boiler with water – see the separate instructions for the vehicle. The boiler can equally well be
used without any freshwater in the boiler.
• Carry out a check as in section 8.
• Start the boiler as described in section ”2:1 Turning the boiler on and off”.
• Select language, this appears when the panel is started for the rst time, see section ”2:11 Tools menu – functions”
point 22.
• Check that the right accessories have a check mark next to them in the list of installed functions, see section 2:15.
• Set the clock, see section ”2:11 Tools menu – functions” point 4.
• Set the desired operating mode (gas and/or electric) and the desired interior temperature, see sections 2:4, 2:5 and
2:6. The LPG boiler and electric elements can be operated simultaneously, but this should be avoided in newly lled
systems due to the risk of air pockets still remaining in the system and that may cause overheating.
These instructions are approved for the The Alde Compact 3020 HE vehicle heater that is CE-marked according to
EN-624 for compliance to the Gas Appliance Regulation. For all relevant harmonised standards and technical speci-
cations see declaration of conformity. The appliance is marked with E5 for installation in vehicles in accordance with
R122 and R10. Installation and repairs may only be carried out by a specialist. Always comply with national regula-
tions.
