24
AFTER SALES SUPPORT
support@scheppach.com.au
1300 855 831
MODEL: HM80L PRODUCT CODE: 60120 04/2018
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Transport/Maintenance/Storage HM80L
IX. Transport (Fig. 1,2)
• Tighten the turntable fastening bolt (23) in order to lock the turntable (15)
• Activate the release lever (4), press the machine head (5) downwards and se-
cure with the machine head locking bolt (22). The saw is now locked in its bot-
tom position.
• Carry the equipment by the carrying handle (1).
• When reassembling the equipment proceed as described under section 7.1.
X. Maintenance
m Warning! Prior to any adjustment, maintenance or service work disconnect the
mains power plug!
General maintenance measures
Wipe chips and dust off the machine from time to time using a cloth. In order to
extend the service life of the tool, oil the rotary parts once monthly. Do not oil the
motor.
When cleaning the plastic do not use corrosive products.
Brush inspection
Check the carbon brushes (located behind the motor cover) after the rst 50 operat-
ing hours with a new machine, or when new brushes have been tted.
After carrying out the rst check, repeat the check every 10 operating hours.
If the carbon is worn to a length of 6 mm, or if the spring or contact wire are burned
or damaged, it is necessary to replace both brushes. If the brushes are found to be
usable following removal, it is possible to reinstall them.
The replacement of the carbon brushes can only be conducted by an expert.
XI. Storage
Store the device and its accessories in a dark, dry and frost-proof place that is in-
accessible to children. The optimum storage temperature is between 5 and 30˚C.
Store the electrical tool in its original packaging.
Cover the electrical tool in order to protect it from dust and moisture.
Store the operating manual with the electrical tool.
