MODEL: HM80L PRODUCT CODE: 60120 04/2018
AUS
HM80L Technical data
VII. Technical data
AC motor 220 - 240 V~ 50Hz
Power
1200 Watt (S1)
1500 Watt (S6 25%)
Idle speed n
0
5000 min
-1
Carbide saw blade ø 210 x ø 30 x 2,6 mm
Number of teeth 48
Swivel range -45° / 0°/ +45°
Mitre cut 0° bis 45° to left
Saw width at 90° 120 x 60 mm
Saw width at 45° 80 x 60 mm
Saw width at 2 x 45° (double mitre cut) 80 x 35 mm
Protection class II
Weight 7.7 kg
Laser class 2
Wavelength of laser 650 nm
Laser output < 1 mW
Laser module power supply 2 x AAA
* S6, continuous operation periodic duty.
Identical duty cycles with a period at load followed by a period at no load.
Running time 10 minutes; duty cycle is 25% of the running time.
The workpiece must have a minimum height of 3mm and a minimum width of
10 mm.
Make sure that the workpiece is always secured with the clamping device.
Noise
Total noise determined in accordance with EN 61029-1.
sound pressure level L
pA
99.6 dB(A)
uncertainty K
pA
3 dB
sound power level L
WA
112.6 d B(A)
uncertainty K
WA
3 dB
Wear hearing protection.
The effects of noise can cause a loss of hearing.
