Assembling and operation HM80L
• Slacken the counter nut (f). Adjust the 45° adjustment screw (25) until the angle
between the saw blade (7) and turntable (15) is precisely 45°.
• Retighten the counter nut (f) to secure this setting.
7.10 Changing the saw blade (Fig. 5-6)
Remove the power plug!
m Caution!
Wear safety gloves when changing the saw blade. Risk of injury!
• Press the release lever (4) and slide back the movable blade guard (6).
• Firmly press the saw spindle lock (28), and slowly turn the ange bolt (26)
clockwise. After max. one turn, the saw spindle lock (28) engages.
• Then undo the ange bolt (26), by applying a slightly greater force in a clock-
wise direction.
• Fully unscrew the ange bolt (26) and remove the outer ange (27).
• Remove the saw blade (7) from the inner ange (29) and pull out in a down-
wards direction.
• Carefully clean the ange bolt (26), outer ange (27) and inner ange (29).
• Insert the new saw blade (7) in the reverse sequence and tighten.
• Warning! The cutting angle of the teeth, in other words the direction of rotation
of the saw blade (7) must coincide with the direction of the arrow on the ma-
chine housing.
• Before continuing your work, make sure that all safety devices are in good
working condition.
• Warning! Every time that you change the saw blade (7), double check to see
that it spins freely in the table insert (12) in both perpendicular and 45° angle
settings.
• Warning! The work to change and align the saw blade (7) must be carried out
correctly.
7.11 Adjusting the laser (Fig. 8)
If the laser (30) ceases to indicate the correct cutting line, you can readjust the
laser.
• Open the laser adjustment screws (35) and set the laser by moving sideways to
that the laser beam strikes the teeth of the saw blade (7).
• Tighten the laser adjustment screws (35).
